LD Systems MON-101A G2, Aktiv Scenemonitor
Beskrivelse
Beskrivelse
- 150W. RMS.
- 99 SPL (1W/1m)
- 10" Koaksiale højttaler med en integreret 1" HF-driver.
- Spredningsvinkel på 75 ° x75 °
- Meget lav følsomhed for feed-back.
- Kortslutningsbeskyttelse og Limiter sikrer pålidelig drift.
- Justerbar volume og afbryder direkte på monitoren.
LD Systems Stinger MON-101A G2
Dette er en særdeles kompakt aktiv monitor, med et meget bredt frekvensområde og et maksimalt lydniveautryk på 121dB.
Specifikationer
Specifikationer
-
FarveSort
Yderligere Specifikationer
Yderligere Specifikationer
Product type
PA loudspeaker
Type
Actives
Low/mid driver dimensions
10 "
Woofer size
254 mm
Woofer type
coaxial loudspeaker
Woofer magnet
Ferrite
Woofer brand
Custom-made
Woofer voice coil
2 "
Woofer voice coil (mm)
50.8 mm
HF driver dimensions
1 "
HF Driver Size
25.4 mm
HF driver magnet
Ferrite
HF driver brand
Custom-made
HF driver voice coil
1 "
HF Driver Voice Coil
25.4 mm
Amplifier
Class A/B
Dispersion (H x V)
75 x 75 °
RMS
150 W
Peak power
600 W
Frequency response
90 - 20000 Hz
Crossover frequency
3300 Hz
SPL (1W/1m)
99 dB
Max. SPL (continuous)
113 dB
Max. SPL (peak)
121 dB
Protection circuits
limiter , short circuit
Controls
On / Off , volume
Indicators
Limit , Power , Signal
Line Inputs
1
Line input connectors
6.3 mm jack , XLR
Line Outputs
1
Line output connectors
XLR
Operating voltage
transformer
Operating voltage
230 V AC / 50-60 Hz
Cabinet material
15 mm Plywood
Cabinet construction
vented
Monitor angle
35 °
Width
380 mm
Depth
335 mm
Height
466 mm
Weight
15,3 kg
Features
ergonomically shaped insert handles
